NOTICE: ThisdocumentprovidesinstructionsforthereplacementoftheWirelessHeartRateSensorontheBowexMaxTrainer
®
M7.
If you need assistance, please call Bowflex Customer Service at 1-800-605-3369.
1. Unplug the AC Power Adapter from the machine and wait 5 minutes.
2. Using a #2 Phillips screwdriver, remove the indicated screw from the
Rear Shroud.
3. Carefully remove the Rear Shroud from the machine. Place a standard
screwdriver behind and near the middle of the Rear Shroud and gently pry
until it releases. Then move the screwdriver to the bottom and gently pry
until the Rear Shroud comes off.
View of the exposed opening (behind Rear Shroud) showing the location
of the Wireless Heart Rate Sensor and Cable:
!
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the
wall outlet and the machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power
cord in a secure location.
Rear Shroud
Wireless Heart
Rate Sensor
Wireless
Heart Rate
Sensor Cable
