Console Does Not Light Up Completely
BEGIN HERE
Remove console hood (8
screws) and check all connec-
tions into console (plug and
unplug). Be sure the cables are
connected securely and
oriented properly. The small
latch on the connector should
line up and snap into place.
Peel off the protective plastic
film on the display. If the plastic
film has already been removed
and the problem remains,
continue with troubleshooting.
Is the entire display
not lighting up?
Go to Troubleshooting:
No Power
NO
Does the issue
persist?
Issue resolved.
YES
Replace the Console
To Next Page
