93
13. Using a 6mm hex wrench, remove the indicated hardware from the
Rail Assembly. Be prepared to support the weight of the Rail Assembly.
Rail Assembly
C
X4
B
A
14. Using new Hardware Items C, B, and A, attach the Rail Assembly to the new Frame Assembly.
Some components of the machine can be heavy or awkward. Use a second person when doing the assembly steps involving these
parts. Do not do steps that involve heavy lifting or awkward movements on your own.
NOTICE: Hand tighten hardware.
To Next Page
