8
Step 4.
NOTICE: Cut the Shipping Zip-Tie that Secures the Cables, Connect the Cables, and Attach the Static Handlebar Assembly and Resistance Level Knob.
Note: Do not let the Cables drop into the Frame Assembly. Do not cut or crimp the Console Cables. Once all hardware has been hand tightened, fully tighten the hardware
with the 5mm hex wrench.
14
X4
O
N
M
15
Item Qty Description Item Qty Description
14 1 Static Handlebar Assembly 15 1 Tray Insert
