32
Installing Your Bowflex Ultimate
®
2 Cables
Cable Installation STEP 3
a. Route Cable down and thread through Pulley
Slider on Chest Bar.
(See Figure A)
b. Replace the Ball Stop. (See Figure B and C)
Figure A Figure B
Slide Ball tightly against
Insert and Cable End
Replace Slotted Insert
Cable End
Figure C
Pulley Slider
Chest Bar
Ball Stop
Slotted Insert
(Rod Pack Removed For Clarity ) (Rod Pack Removed For Clarity )
To Next Page
