Figure 20b - Left Main Assembly Pulleys
Step 20b - Cable & Pulley Routing
Connect Left Squat Cable through the Floating and Main Assembly Pulleys
Repeat the same procedure completed during Step 20 for the Left Squat Cable.
Left Squat Cable
Cable Shroud
