3.5 mm TRS Receiver (BY-V4-RX35)
❶ 3.5 mm TRS Connector
It can be connected to a camera, voice recorder, or other
mobile device featuring a 3.5 mm TRS port.
❷ USB-C Charging Port
❸
Power Button
• Press and hold for 2 seconds to power on or off.
• Press and hold for 5 seconds to enter pairing status in shutdown
mode.
❹
Status Indicator
❺ 2TX / 4TX Switch
Toggle it between 2TX and 4TX to pair the receiver with two
transmitters (2TX) or four transmitters (4TX).
Status
Indicator
Unpaired
Blinking blue and red alternately
Pairing
Blinking blue rapidly
Paired successfully
Static blue
Low Battery
Blinking red
Charging (in shutdown mode)
Static red
