Moto3 User Manual
Structure of motorcycle
Parts name
1. Clutch lever
2. LH rear mirror
3. Speedometer
4. Power switch
5. RH rear mirror
6. Front brake lever
7. LH handlebar
8. LH handlebar switch
9. Fuel tank lock
10. RH handlebar switch
11. Throttle grip
2 3 4 5
1 6
7 8 9 10 11
