Moto3 User Manual
Main parameters
Model Data MODEL Data
Length 2030mm Braking deceleration Follow GB20073
Width 720mm Maximum gradeability >25”
Height 1120mm Bore x Stroke 65.5x67
Wheel base 1345mm Pressure ratio 9.0:1
Curb weight 153kg Maximum net power/Rotational speed 13kw/8000r/min
Load capacity I50kg (With driver) Maximum torque/Rotational speed 17N.m/6000r/min
Allowed maximum weight 303kg Idling rotational speed (1500+150)r/min
Load capacity of front axle 107kg Working volume of Cylinder 250ml
Load capacity of rear axle 196kg Spark plug D8EA
Size of front tyre 110/70-17 Clarence of spark plug (0.6-0.7)mm
Size of rear tyre 140/70-17 Air inlet valve: (0.04-0.06)mm
Maximum designed speed 115km/h Air outlet valve: (0.04-0.06)mm
