Moto3 User Manual
Table of fastening parts
Ref. No. Position of fastening parts Torque specification (N • m)
1 Specification for engine hanging fastening parts M8X1.25:(30~40)
M10X1.25:(35~45)
2 Specification for front shock absorber’s fastening parts M8X1.25:(22~32)
M14X1.5:(65~75)
3 Specification for front brake fastening parts M8X1.25:(35~41)
M8X1.25:(17~23)
4 Specification for rear wheel axle fastening parts M14xl.5:(65~75)
5 Specification for steering stem, fastening parts M22X1: (65-75)
M25X1: (21-26)
6 Specification M6X1.25:(10~14)
M8X1.25:(22~32)
7 Specification M12X1.25(55-61)
8 Specification M10X1.25:(35—45)
9 Specification M8X1.25:(17~23)
10 Specification M14X1.25:(65~75)
Maintenance periodic table
Maintenance should follow stipulated period (Refer to table next page)
“*“ Means done by maintenance station. If you have the specialized tools, spare parts and know how, maintenance could
be done, refer to service manual for details.
“**” Indicates for safety purpose, done by braaap maintainer only.
Note:
1. Frequently wash in dusty region.
2. When odometer record higher than given highest data, maintenance period still follow stipulated mileage interval and
repeatedly perform.
