Bradco 617 - Page 50

OPERATING INSTRUCTIONS
OPERATING TECHNIQUES
SKID STEER TRENCHERS
G
G
5791
2-26-92
When trenching, remember to keep in mind the spoil placement.
Position the trencher so that the auger floats at ground level to move spoil
away from the trench. (See Figure #9)
FIGURE #9
FIGURE #8
CREEP IN REVERSE
LOWER
TRENCH
NOTE DIGGING ANGLE
AUGER AT
GROUND LEVEL
SPOIL PILE
