DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS

DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS

DIGGING CHAIN OPTIONS

2.00" PITCH DIGGING TOOTH STATION BREAK DOWN

J

J

DIRT TOOTH, LEFT

PART #54431

DIRT TOOTH, RIGHT

PART #54432

12" CHAIN SPACER

PART #54442

4.50" CAPSCREW

PART #1351

WITH FLAT WASHER #1527

AND NUT #1692

8.50

5811

3-2-92

12" STATION
