Bradco 617 - Page 79

DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS
DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS
DIGGING CHAIN OPTIONS
2.00" PITCH DIGGING CHAIN WIDTH CONVERSIONS
J
J
4) FROM 10" WIDE TO 6" WIDE
REQ’D PART NO. DESCRIPTION
8 1347 .50"UNF X 3.25" Capscrew
4 54628 Spacer Tube
4 54440 Spacer Tube
1 53054 6" Crumber Shoe
5) FROM 6" WIDE TO 12" WIDE
REQ’D PART NO. DESCRIPTION
12 1692 .50" UNF High Hex Nut
28 1351 .50"UNF X 4.50" Capscrew
12 1527 .50" SAE Flat Washer
3 54431 Left Tooth
3 54432 Right Tooth
3 54441 10" Chain Spacer
3 54442 12" Chain Spacer
1 53059 12" Crumber Shoe
8 54439 8" Spacer
6) FROM 12" WIDE TO 6" WIDE
REQ’D PART NO. DESCRIPTION
16 1347 .50"UNF X 3.25" Capscrew
4 54628 Spacer Tube
8 54440 Spacer Tube
1 53054 6" Crumber Shoe
7) FROM 8" WIDE TO 10" WIDE
REQ’D PART NO. DESCRIPTION
8 1692 .50" UNF High Hex Nut
12 1347 .50"UNF X 3.25" Capscrew
2 54431 Left Tooth
2 54432 Right Tooth
4 54441 10" Chain Spacer
1 53058 10" Crumber Shoe
8) FROM 10" WIDE TO 8" WIDE
REQ’D PART NO. DESCRIPTION
4 1351 .50"UNF X 4.50" Capscrew
2 54628 Spacer Tube
6 54440 Spacer Tube
2 54439 8" Spacer
1 53055 8" Crumber Shoe
6674
10-4-95
