DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS
DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS
DIGGING CHAIN OPTIONS
2.00" PITCH DIGGING CHAIN WIDTH CONVERSIONS
J
J
9) FROM 8" WIDE TO 12" WIDE
REQ’D PART NO. DESCRIPTION
12 1692 .50" UNF High Hex Nut
4 1347 .50"UNF X 3.25" Capscrew
8 1351 .50"UNF X 4.50" Capscrew
12 1527 .50" SAE Flat Washer
3 54431 Left Tooth
3 54432 Right Tooth
3 54441 10" Chain Spacer
3 54442 12" Chain Spacer
1 53059 12" Crumber Shoe
10) FROM 12" WIDE TO 8" WIDE
REQ’D PART NO. DESCRIPTION
2 54628 Spacer Tube
10 54440 Spacer Tube
2 54439 8" Spacer
1 53055 8" Crumber Shoe
11) FROM 10" WIDE TO 12" WIDE
REQ’D PART NO. DESCRIPTION
4 1692 .50" UNF High Hex Nut
12 1351 .50"UNF X 4.50" Capscrew
12 1527 .50" SAE Flat Washer
1 54431 Left Tooth
1 54432 Right Tooth
3 54442 12" Chain Spacer
1 53059 12" Crumber Shoe
12) FROM 12" WIDE TO 10" WIDE
REQ’D PART NO. DESCRIPTION
8 1347 .50"UNF X 3.25" Capscrew
4 54440 Spacer Tube
1 54441 10" Chain Spacer
1 53058 10" Crumber Shoe
CHAIN CONVERSIONS FOR 36" BOOMS - TOOTH EVERY STATION
1) FROM 6" WIDE TO 8" WIDE
REQ’D PART NO. DESCRIPTION
22 1351 .50"UNF X 4.50" Capscrew
2 54440 Spacer Tube
11 54439 8" Spacer
1 53055 8" Crumber Shoe
6675
10-4-95
