13
=01<=01=<CT
<=16<
TLS2200 THERMAL_
=01<=01=<CT<
=31< LABELING
SYSTEM
The status bar indicates that
the cursor is located at the 16
th
character position.
As you continue to enter text, the
screen scrolls to allow the entry
of the remaining text (underlined
“M” is at cursor position 31).
Cursor and Editing Keys
Enter
• Activates a screen selection
• When composing a legend, inserts a non-visible end of line
character and moves the cursor down to the next line.
• Clears system messages from display
<
Moves the cursor one character to the right. If at the rightmost
position on the display, then the display is scrolled one character
to the left and the cursor remains at the rightmost position.
=
Moves the cursor one character to the left. If at the leftmost
position on the display, then the display is scrolled one character
to the right and the cursor remains at the leftmost position.
>
Displays the previous line of text (if any).
?
Displays the next line of text (if any).
Shift + <
Skip to the beginning of the next word.
Shift + =
Skip to the beginning of the previous word.
Delete
• While in text editor, deletes the character at the cursor position.
• Backs you out one level in the Setup menu tree.
• Terminate the printing of markers.
Shift + Delete
Backspaces as it deletes characters. If cursor is at the first
character position on a line, the carriage return is deleted and any
text on the line is appended to the text on the previous line.
Legend Clear
Clears all characters on the current label line.
Shift + Legend Clear
Clears all characters on the label.
Shift + Form Clear
Deletes all characters and lines on the label, and resets the font
size to the default value.
Cap Lock
Toggles between upper and lowercase characters
NOTE: Current Cap Lock status is retained when unit is turned
OFF.
To Next Page
