16
WIRING DIAGRAMS
8
Typical Multi-Stage 2 Heat / 1 Cool
THERMOSTAT TERMINAL BLOCK
MULTI-STAGE 2 HEAT / 1 COOL SYSTEM
R
R
Y or Y1
W1
W2
G
C
Y1 Y2 W1
W2
G
O
B C
Typical Multi-Stage 2 Heat / 2 Cool
THERMOSTAT TERMINAL BLOCK
MULTI-STAGE 2 HEAT / 2 COOL SYSTEM
R
R
Y1
W1
W2
G
C
Y1 Y2 W1
W2
G
O
B C
Y2
Braeburn Systems LLC warrants each new Braeburn thermostat
against any defects that are due to faulty material or
workmanship for a period of two years after the original date of
purchase by a professional service technician. This warranty
and our liability does not apply to batteries, nor does it include
damage to merchandise or the thermostat resulting from accident, alteration, neglect, misuse,
improper installation or any other failure to follow Braeburn installation and operating
instructions.
Braeburn Systems LLC agrees to repair or replace at its option any Braeburn thermostat
under warranty provided it is returned postage prepaid to our warranty facility in a padded
carton within the warranty period, with proof of the original date of purchase and a brief
description of the malfunction. This limited warranty does not include the cost of removal or
re-installation.
WARRANTY
YEAR
LIMITED
This warranty gives you specific legal rights and you may also have other rights that vary from
state to state or province to province. Answers to any questions regarding our limited
warranty may be obtained by writing our corporate offices.
Braeburn Systems LLC
2215 Cornell Avenue • Montgomery, IL 60538
Technical Assistance: www.braeburnonline.com
866-268-5599
© 2004 Braeburn Systems LLC All Rights Reserved.
Warranty Facility:
Braeburn Systems LLC
Attn: Warranty Department
2215 Cornell Avenue
Montgomery, IL 60538
