5 User Manual
Room Temperature ...................... Displays the current room temperature
Lock Mode Indicator ................... Indicates if the thermostat is locked
Set Temperature .......................... Displays the current set point temperature
Reset Button ............................... Resets current time, program and user settings
Service Indicators ...................... Displays various service/maintenance information
Program Event Indicator.............. Displays the current program event
Time of Day ................................. Displays the current time of day
Hold Mode Indicator ................... Indicates if the thermostat is in HOLD mode
System Status Indicator ............. Displays information about the status of the system
Day of the Week ........................... Displays the current day of the week
SpeedBar
®
.................................... Increases or decreases settings (time, temperature, etc.)
Quick Reference Instructions ...... Stored in slot located at top of thermostat
Fan Indicator ................................ Indicates when the system fan is running
Low Battery Indicator .................. Indicates when the batteries need to be replaced
1
2
3
4
5
6
7
8
9
10
11
Battery Compartment ..........................Located in the back of thermostat
12
13
14
Thermostat and Display
