Display features
Page 7
MON TUE WED THU SUNSATFRI
HEAT WAIT
RESET OFF
HOME
AWAY
WAKE
SLEEP
AUTO
ON
MAN
- Burners are alight:
- Inner flame flashing - low gas rate.
- Outer flame flashing - high gas rate.
- Temperature:
- Displays approximate current temperature.
- Temporarily displays set temperature when the
up or down arrow is pressed, reverts back to
current temperature after 5 seconds.
- Displays current time (once it has been set).
- Room fan symbol - rotates when room fan is
running.
- Replace batteries - 3 x AAA (good quality alkaline
batteries are recommended).
- Service call required.
- ON indicates that remote control has been turned
on. The heater will operate as required to achieve
the set temperature.
ON
- OFF indicates that remote control is turned
off. The heater will not operate.
OFF
