2. Pin Outs...
ED-549 : 8 Analogue InputsED-588 : 8 digital outputs and 8 digital inputs
ED-560 : 4 Analogue Outputs
Type of
Port
Terminal
Block
Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
Analogue
Out
Yellow AGND VOUT 0 VOUT 1 IOUT 0 IOUT 1
Expansion Grey GND RS-485 D- RS-485 D+ RS-485 D+ RS-485 D-
Analogue
Out
Green AGND VOUT 2 VOUT 3 IOUT 2 IOUT 3
Power Black -V +VA +VB -V Func. GND
Type of
Port
Terminal
Block
Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
Analogue In Yellow AGND AIn 0- AIn 0+ AIn 1- AIn 1+
Analogue In Orange AGND AIn 2- AIn 2+ AIn 3- AIn 3+
Expansion Grey SIG GND RS-485 D- RS-485 D+ RS-485 D+ RS-485 D-
Analogue In Green AGND AIn 4- AIn 4+ AIn 5- AIn 5+
Analogue In Blue AGND AIn 6- AIn 6+ AIn 7- AIn 7+
Power Black -V +VA +VB -V Func. GND
