100-214-276 Rev. 3 7-7
2000X aed Actuator Chapter 7: Maintenance
Instruction Manual Parts Lists
Purple (Ti), Ratio 1:0.6 101-149-124
Boosters - 40kHz (Same as XL: 8 mm)
Black (Ti), Ratio 1:2.5 101-149-084
Silver (Ti), Ratio 1:2.0 101-149-083
Gold (Ti), Ratio 1:1.5 101-149-086
Green (Ti), Ratio 1:1 101-149-085
Black (Al), Ratio 1:2.5 101-149-082
Silver (Al), Ratio 1:2.0 101-149-081
Gold (Al), Ratio 1:1.5 101-149-080
Green (Al), Ratio 1:1 101-149-079
Purple (Al), Ratio 1:0.6 101-149-087
Solid Mount Boosters - 40kHz (Same as XL: 8mm)
Black (Ti), Ratio 1:2.5 109-041-174
Silver (Ti), Ratio 1:2.0 109-041-175
Gold (Ti), Ratio 1:1.5 109-041-176
Green (Ti), Ratio 1:1.0 109-041-177
Purple (Ti), Ratio 1:0.6 109-041-178
Table 7.3 Spare Parts List for the 2000X Actuator
Description EDP Number
Linear Encoder Assembly 100-143-161
RF Harness Assembly 100-246-1282
RF Contact Block Assembly 100-246-909
S-Beam Assembly 100-246-1276
Cooling Valve Assembly 100-246-896
Solenoid Valve 100-246-901
Downspeed Control Assembly (Flow Control 1 1/2 - 2"cyl) 100-246-1310
Table 7.2 Accessories List for 2000X aed Actuator (Continued)
Description EDP Number
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
