Electrical Connections
6-10
Digital Compact
Fre-
quency
memory
Reset frequency memory
The frequency is reset by
the external reset signal.
5 - ON
5 - OFF
Amplitude
control
External:
(50 % to 100%)
controlled by customer.
CAUTION: Before applying
an external amplitude make
sure pin 6 is in "ON" posi-
tion.
6 - ON
6 - OFF
Internal
:
The module maintains fixed
amplitude.
Ramp
start
Short:
Sets ramp time to 10 ms
7 - OFF
8 - OFF
Medium
:
Sets ramp time to 35 ms
7 - ON
8 - OFF
Standard
:
Sets ramp time to 80 ms
7 - OFF
8 - ON
Long
:
Sets ramp time to 105 ms
7 - ON
8 - ON
Tab. 6-4 DIP switch settings for additional functions
(default settings are bold.)
