Technical Specifications
Product Specifications
Input Power
(selected at time of order)
120 VAC, 50/60 Hz, 0.2 A
24 VAC, 50/60 Hz, 1.0 A
Installation Category II (local level, over-voltage transients less than 500V)
Storage Temperature -50°C to 120°C (-58°F to 248°F)
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Humidity 10% to 90% (non-condensing)
Ventilation Control Relays 125 VAC, 50/60 Hz, 5 A resistive, 250 VA inductive
Internal Alarm 106 dB @ 10 cm, 3.8 kHz piezoelectric element
Front Panel Indicators Power (green LED)
Alert 1 (red LED)
Alert 2 (red LED)
Alarm (red LED)
Sensor 1 (yellow LED)
Sensor 2 (yellow LED)
Sensor 3 (yellow LED)
Sensor 4 (yellow LED)
Zone 1 (yellow LED)
Zone 2 (yellow LED)
Display 4-digit numeric
Selectable Fan Settings 2-speed motor fans
2 individual fans
Alert Levels 8 field selectable choices
Delay Times 0 to 7 minutes, both entrance and exit
Dimensions 8.15” W x 9.93” H x 2.70” D (21 cm W x 25 cm H x 7 cm D)
Weight 5.5 lbs (2.49 kg)
Housing Gray, NEMA 3R, polycarbonate plastic
Compliance ANSI/ISA 92.00.01-2010 (R2015)
EN 50270
FCC Part 15 Subpart B
RoHS
IOM01
Rev 1.0 – December 22, 2020 6
