2.2 Components and their functions
Item
COMPONENT
FUNCTION
1
Plug
12 V power supply for the remote control
2
Adjusting screw
Setting the control pressure at the pressure regulating
valve
3
LUV recess
Holder to attach the LUV to the tractor
4
Shaft holder
Holder for accessories (dimensions 50x25)
5
Feeler holder
Toothed disk to set the feeler position
6
Crow's foot blade
Tool to cut the roots of weeds between the rows of vines
7
Feeler
Sensing the plant
8
Feeler hoop
Lever to operate the control valve
9
Hydraulic
connection (P)
Hydraulic connection to the tractor, under pressure
10
Hydraulic
connection (T)
Tank connection, return flow to the tractor, not under
pressure
11
Remote control
For manual actuation of the LUV
2.3 Technical data
2.3.1 Performance and operating values
 Min. drive rating
20 kW
 Min. travelling speed
unlimited
 Max. travelling speed
8 km/h
 Max. working depth
150 mm
 Oil supply
7 – 12 l (one side) / 12 – 24 l (both sides), max. 180
bar
2.3.2 Dimensions
(H x W x D) mm
 Transport
590 x 180 x 460
Installation/working
590 x 430 (610) x 460
2.3.3 Weight
 Transport weight
30 kg
 Weight in use
28.8 kg
