Bray 6A series Quick Start Guide

SERIES 6A ELECTROPNEUMATIC POSITIONER
QUICK START GUIDE
10 of 12© 2021 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM The Information
contained herein shall not be copied, transferred, conveyed, or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International, Inc.
4.0 POSITIONER OPTIMIZATION
Step  This is an example of screen with
increased deadband responsiveness
Step 
Use the Menu Button
to scroll to
parameter  (YCLS) This setting allows
users to assign a position where the A
will default to full open or close Select
‘uP do’ by pressing the Up Button
 uP – Only Upper Limit (Full Open)
 do – Only Lower limit (Tight Close)
 uP do – Upper and Lower limits set
Step 
Use the Menu Button
to scroll to
parameter  (YCDO tight close)
Step  Change the parameter value to the
desired lower limit for tight closing
Example If the positioner is at  or
lower the actuator automatically goes to
full close
