6 PS-500 User Instructions
2 Specifications
2.1 Scale Platform
2.1.1 Capacity
l 250 kg x 0.1 kg
l 500 lb x 0.2 lb
l 500 lb x 5 oz
2.1.2 Dimension
l 22” L x 22” W x 2” H
m 559 mm (L) x 559 mm (W) x 51 mm (H)
l 36” L x 22” W x 2” H
m 906 mm (L) x 559 mm (W) x 51 mm (H)
l 42” L x 22” W x 2” H
m 1067 mm (L) x 559 mm (W) x 51 mm (H)
2.1.3 Options
l Table top stand
l Floor stand
2.2 Scale Indicator
l Input signal range: 0mV - +30mV
l Sensitivity: >0.2µV/grad
l Internal Resolution: Approximately 520,000 counts
l Display Resolution: can be selected between 500-100,000
l System Linearity: within 0.01% of Full Scale
l Calibration Method: Software calibration with long-term storage in EEPROM
2.2.1 Power Supply
l Alkaline batteries: 4 AAA size cells (20 hour battery life)
l AC adapter: 6VDC, 500mA with central negative
l Work current: .25mA
m (when voltage in 5Vdc-8Vdc and not include loadcell consumption)
