PS1000/2000 User Instructions 7
2.2.2 Dimension
l 6.5” L x 3.2” H x 1.2” W
m 164 mm (L) x 762 mm (W) x 64 mm (H)
2.2.3 Display
l 5-digit,7-segment, 0.625" (16mm) LCD
2.2.4 Keypad
l 4 push button keys
2.2.5 Environment
2.2.6 Load Cell Excitation
Because more than one load cell can be used on a scale, the following are required for
the load cell set to be used with this indicator.
2.2.7 Communication
Working temperature 5° to 35°C
Storage temperature -10°C to 70°C
Humidity ≤95% RH without condensation
Voltage 4.4VDC
Max. Current 55mA (can power 4-350 ohm loadcells)
Signal connection 4 or 6 lead with sense leads
Max Sensitivity 0.3mV/V to +3mV/V (must be fit to >0.2µV
/display grad)
Input Resistor ≥80 Ω
Output Resistor <10 KΩ
Mode Full-duplex or only output mode can be selected
Baud Rate Selectable: 1200-2400-4800-9600-19200 bps
Data Format 7 data bits, even or odd parity, 1 stop bit
8 data bits, non-parity, 1 stop bit
Protocol 7 selected protocols (one compatible with NCI standard SCP-01)
Output Data gross weight, net weight, tare weight, indicator displaying weight, weighing unit etc.
