PS1000/2000 User Instructions 9
3.3 Display
The PS-500 indicator utilizes a 7 segment LCD (Liquid Crystal Display) providing the
weight and system information.
Arrows will illuminate to designate the current mode.
Figure 3.1 PS-500 Display
Table 3.1 LCD Display Annunciators and Definitions
Display Symbol Description
ZERO The scale is at zero point and the gross weight is 0.
HOLD The scale is in HOLD mode.
The current live weight is being displayed when the arrow flashes. The current weight is
locked when the arrow does not flash.
NET Indicates net mode and the tare weight is not 0.
lb Indicates the current unit of measure is lb.
oz Indicates the current unit of measure is oz.
kg Indicates the current unit of measure is kg.
