6 PS1000/2000 User Instructions
2 Specifications
2.1 Scale Platform
2.1.1 Capacity
l PS1000: 500 kg x 0.2 kg / 1,000 lb x 0.5 lb
l PS2000: 1000 kg x 0.5 kg / 2,000 lb x 1.0 lb
2.1.2 Dimension
l PS1000: 55.75” L x 20.25” W x 2.5” H
m 1416 mm (L) x 514 mm (W) x 64 mm (H)
l PS2000: 59” L x 30” W x 2.5” H
m 1498 mm (L) x 762 mm (W) x 64 mm (H)
2.1.3 Options
l Table top stand
l Floor stand
2.2 Scale Indicator
l Input signal range: 0mV - +30mV
l Sensitivity: >0.2µV/grad
l Internal Resolution: Approximately 520,000 counts
l Display Resolution: can be selected between 500-100,000
l System Linearity: within 0.01% of Full Scale
l Calibration Method: Software calibration with long-term storage in EEPROM
2.2.1 Power Supply
l Alkaline batteries: 4 AAA size cells (20 hour battery life)
l AC adapter: 6VDC, 500mA with central negative
l Work current: .25mA
m (when voltage in 5Vdc-8Vdc and not include loadcell consumption)
