Breckwell P23FS - Introduction

Thank you for purchasing the Breckwell Pellet
Burning Stove. You are now prepared to burn
wood in the most efficient, convenient way possible.
To achieve the safest, most efficient and most
enjoyable performance from your stove, you must
do three things: 1) Install it properly: 2) Operate it
correctly and; 3) Maintain it regularly. The purpose
1.0 INTRODUCTION
Your Breckwell P23 comes as a fireplace insert or a freestanding
pellet stove.
of this manual is to help you do all three. PLEASE
read this entire manual thoroughly before
installation and use of this pellet stove. KEEP IT
In a handy place for future reference and future
owners. Failure to follow these instructions
could result in property damage, bodily injury
or even death.
The stove will not operate using natural draft, or without a
power source for the blower systems and fuel feeding systems
and must not be burned with any type of coal (see section 3.1).
This stove has been independently tested and approved in
accordance with the relevant portions of ULC S627 CSA
B366.2-M1983 "Standard for Space Heaters for use with Solid
Fuels", UL 1482-1988 "Standard for Room Heaters", ASTM
standard El509-93, CSA C22.2 No. 3 “Electrical Features of
Solid Fuel Burning Appliances", Oregon new rules for mobile
homes (814-23-900 through 814-23-909) and installation as
a stove heater.
This appliance is designed specifically for use only with
pelletized wood, it is designed for residential installation
according to current national and local building codes as a
room heater. It is also approved as a mobile home heater
which is designed for connection to an outside combustion air
source.
This stove is designed to provide the optimum proportions of
fuel and air to the fire in order to burn free of smoke and soot.
Any blockage of the air supply to or from the stove will
seriously degrade the performance and will be evidenced by
a smoking exhausl and a sooting window. For the best
operation the ash content of the pellet fuel should be less than
1% and the calorific value approximately 8200 BTU/LB. Avoid
high ash content fuels as this will rapidly fill up the burn pot and
eventually cut off the combustion air supply.
Commercial arid industrial Installations of Breckwell
Pellet Stoves are strongly discouraged since operational
control is often not well managed In these settings.
CONTENTS
2.0 Installation
2.1 Preparation
2.2 Clearances
2.3 Combustion Air Supply
2.31 When Outside Air is Not Used
2.4 Venting
2.41 Freestanding Installations
2.42 Insert Installations
2.5 Electrical Installation
2.6 Special Mobile Home
Requirements
3.0 Operation
3.1 Proper Fuel
3.2 Pre-Startup Check
3.3 Building a Fire
3.31 Using Approved Fire Starter
3.32 Optional Hot Rod ™
3.4 Panel Controls
3.5 Damper Control
3.6 Refueling
3.7 Shut Down Procedure
3.8 Safety Features
3.9
Operating Safety Precautions
4.0 Maintenance
4.1 Ash Disposal
4.11 Vacuum Use
4.2 Cleaning
4.3 Blowers
4.4 Chimney Cleaning
4.5 Recommended Maintenance
Schedule
5.0 Trouble Shooting Guide
5.1 Fuel Will Not Feed
5.2 Fire Goes Out
5.3 Smoky Fire
5.4 No Power
5.5 Blowers Will Not Operate Properly
5.6 Noisy Operation
6.0 Replacement Parts and
Wiring Diagram
PAGE 2
