Bredel 20 - Barbed Nipple Assembly (PTFE;PDVF)

SPECIFICATIONS
58
11.5.5 Barbed nipple assembly (PTFE/PDVF)
Pos. Qty. Description Bredel 10 Bredel 15 Bredel 20
1 2 Rubber bush 210119 215119 215119
2 2 Hose clamp C112507 C112508 C112508
3 2 Barbed nipple PTFE 210688010 215688015 215688020
Barbed nipple PVDF 210690010 215690015 215690020
4 2 Bracket 210197 215197 215197
5 4 Bolt, Hex. head F504036 F504054 F504054
6 4 Washer F532008 F532009 F532009
