SPECIFICATIONS
60
11.5.7 Flange assembly (1)
Pos. Qty. Description Bredel 10 Bredel 15 Bredel 20
1 2 Rubber bush 210119 215119 215119
2 2 Hose clamp C112507 C112508 C112508
3 2 Bracket 210197 215197 215197
4 4 Bolt, Hex. head F504036 F504054 F504054
5 4 Washer F532008 F532009 F532009
6 2 Threaded nipple (BSP) SS 210693010 215693015 215693020
7 2 Nut F519003 F519004 F519004
8 2 Flange DIN SS A304504 A304505 A304505
2 Flange ASA SS A305504 A305505 A305505
