3.1.1 INSTALL WIND VANE
With reference to photo below, (a) locate and align the at are on the wind vane shaft to the
at surface on the wind vane and push the vane onto the shaft. (b) tighten the set screw with a
precision screwdriver.
Step 1 Step 2
3.1.2 INSTALL RAIN GAUGE FUNNEL
Install the rain gauge funnel and rotate clockwise to lock the funnel to the sensor array
Lock
grooves
Step 2
Step 1
3.1.3 INSTALL RECHARGEABLE BATTERIES
Step 1: Unscrew the battery door at bottom of unit and
take out the cable socket.
Step 2: Connect the Ni-MH rechargeable battery plug to
the socket.
