50
Step 1: Loosen the screw lightly until the gears on the
opposite side separated from lock position.
Step 2: Adjust the vertical angle of the solar panel (0°,
15°, 30°, 45°, 60°) according to the latitude of your
location.
Step 3: Push the gear and tighten the screw until the
gears are securely locked.
3.1.5 INSTALL MOUNTING POLE
Mounting kit set
1. Pole mounting stand x 1 2. Mounting clamp x 1 3. Plastic pole x 1
4. screws x 4 5. Hex nuts x 4 6. Flat washers x 4
7. screw x 1 8. Hex nut x 1
