Cooling System
Dirt or debris can restrict air flow and cause the
engine to overheat, resulting in poor
performance and reduced engine life. Continued
operation with a clogged cooling system can
cause severe overheating and possible engine
damage. Clean these areas yearly or more often
when dust or airborne debris is present (Figures
18, 19, 20).
NOTICE: Do not use water to clean the engine.
Water could contaminate the fuel system. Use a
brush or dry cloth to clean the engine.
Figure 18 - Static Screen
Figure 19 - Rotating Screen
Figure 20 - Ducting & Cylinder Fins
WARNING
Running engines produce heat.
Severe burns can occur on contact.
• Allow muffler, engine cylinder fins, and radiator
to cool before touching.
• Remove accumulated combustibles from muf-
fler area and cylinder area.
