10 BRIGGSandSTRATTON.COM
The gross power rating for individual petrol engine models is labeled in accordance with SAE (Society of Automotive Engineers) code
J1940 Small Engine Power & Torque Rating Procedure, and is rated in accordance with SAE J1995. Torque values are derived at 2600 RPM for those
engines with “rpm” called out on the label and 3060 RPM for all others; horsepower values are derived at 3600 RPM. The gross power curves can be
viewed at www.BRIGGSandSTRATTON.COM. Net power values are taken with exhaust and air cleaner installed whereas gross power values are
collected without these attachments. Actual gross engine power will be higher than net engine power and is affected by, among other things, ambient
operating conditions and engine-to-engine variability. Given the wide array of products on which engines are placed, the petrol engine may not develop
the rated gross power when used in a given piece of power equipment. This difference is due to a variety of factors including, but not limited to, the
variety of engine components (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions
(temperature, humidity, altitude), and engine-to engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an
engine of higher rated power for this engine.
* This water pump is rated in accordance with Briggs & Stratton standard 621K.
Model 073010
Suction and Discharge Port Diameter....50 mm (2 in)
Maximum Suction Head * ...............8 m (26 ft)
Maximum Discharge Head * ............25 m (82 ft)
Maximum Discharge Capacity
* 600 l/min (159 US gal/min)
Displacement ...................206 cc (12.48 in
3
)
Oil Capacity........................0.59 l (20 oz)
Model 073011
Suction and Discharge Port Diameter....76 mm (3 in)
Maximum Suction Head * ...............8 m (26 ft)
Maximum Discharge Head * ............25 m (82 ft)
Maximum Discharge Capacity
* 939 l/min (248 US gal/min)
Displacement ...................206 cc (12.48 in
3
)
Oil Capacity........................0.59 l (20 oz)
Engine Oil Bottle ....................................................................100005E or 100007E
Synthetic Oil Bottle ........................................................................... 100007W
Fuel Stabilizer .......................................................................992380 or 992381
Problem Cause
running
1. Pump not primed.
2.
Suction or discharge hose restricted,
collapsed, damaged, too long, or diameter
too small.
3. Strainer not completely under water.
4. Air leak at suction hose connector.
5. Strainer clogged.
6. Excessive or marginal head.
7. Engine speed lever is in SLOW position.
1. Fill pump chamber with water and prime pump.
2. Replace suction or discharge hose.
3. Sink the strainer and the end of suction hose
completely under water.
4
.
Replace sealing washer if missing or damaged.
Tighten hose connector and clamp.
5. Clean debris from strainer.
6.
Relocate pump and/or hoses to reduce head.
7.
Move engine speed lever to FAST position.
1. Rocker switch set to OFF (0).
2. Fuel shutoff is in OFF (0) position.
3. Dirty air cleaner.
4. Out of fuel.
5. Stale or contaminated fuel or water in fuel.
6
. Spark plug wire not connected to spark plug.
7. Bad spark plug.
8. Excessive fuel is present in the air/fuel
mixture causing a “flooded” condition.
9. Carburetor is out of adjustment.
1. Set switch to ON (I).
2. Turn fuel shutoff to ON (I) position.
3. Clean or replace air cleaner.
4. Wait two minutes and fill fuel tank.
5. Drain fuel tank and carburetor; fill with fresh
fuel.
6. Connect wire to spark plug.
7. Replace spark plug.
8. Wait 5 minutes and re-crank engine.
9. Contact Authorized service facility.
Engine
when running.
Out of fuel. Wait two minutes and fill fuel tank.
Model 073035
Suction and Discharge Port Diameter .......50mm (2 in)
Maximum Suction Head * ..................8 m (26 ft)
Maximum Discharge Head * ...............25 m (82 ft)
Maximum Discharge Capacity
* 435 l/min (115 US gal/min)
Displacement........................127 cc (7.74 in
3
)
Oil Capacity ............................0.59 l (20 oz)
