BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC

MILWAUKEE, WISCONSIN, U.S.A.

Water Pump

Operator’s Manual

Bomba de agua

Manual del Operario

Bomba de Água

Manual do Operador

Pompe à eau

Manuel d’utilisation

Pompa wodna

Instrukcja obsługi

Vesipumppu

Ohjekirja

Водяной насос

Руководство по эксплуатации

Su Pompası

Kullanma Kılavuzu

Original Instruction

Appearance may vary slightly

MS10408 (REV. -)

WP20, WP2-35, WP30

en

es

pt

fr

pl

fi

ru

tr

pt

Português

fi

Suomi

Table of Contents

Questions and Answers:

M
Marilyn MillerJul 31, 2025
Why Briggs & Stratton WP20 Water Pump engine won't start?
- A
  Alicia SullivanJul 31, 2025
  If your Briggs & Stratton Water Pump engine won't start, lacks power, runs rough, or falters, consider these potential causes: Ensure the rocker switch is set to 'On' and the fuel shutoff is in the 'On' position. Check the air cleaner and clean or replace it if dirty. Make sure there's fuel in the tank; if empty, wait two minutes before refueling. Drain the fuel tank and carburetor and refill with fresh fuel if the current fuel is stale or contaminated. Verify the spark plug wire is connected, and replace the spark plug if it’s bad. If the engine is flooded, wait 5 minutes and try re-cranking.
V
Victoria WarrenAug 14, 2025
What to do if my Briggs & Stratton Water Pump has low output?
- M
  Michael CantuAug 14, 2025
  If your Briggs & Stratton Water Pump has low output, several factors could be responsible. First, ensure the pump is correctly primed by filling the pump chamber with water. Check the suction hose for restrictions, collapse, damage, or excessive length, and replace it if necessary. Make sure the strainer is fully submerged. Inspect the suction hose connector for air leaks, replacing the sealing washer and tightening the connector and clamp if needed. Clean any debris from the strainer. Verify that the discharge hose isn't restricted, damaged, or too long, replacing it if needed. Reduce the head by relocating the pump or hoses. Finally, ensure the engine speed lever is in the 'Fast' position.
