Brightlink 16x16 - Page 12

12
13
OUT xx ON/OFF
Set OUTPUT:xx On Or Off
14
OUT xx FR yy
Set OUTPUT:xx From INPUT:yy
15
OUT xx EH/ET
Set OUTPUT:xx Use HDMI/HDBT EDID
xx=[00]: All OUTPUT Port, [01...08]: OUTPUT Port
yy=[01...08]: INPUT Port
16
POH TX yy ON/OFF
Set OUTPUT:yy POH On Or Off
yy=[00]: All OUTPUT Port, [01...08]: OUTPUT Port
17
VLC TX yy ON/OFF
Set OUTPUT:yy Valens Long Cable Mode On Or Off
yy=[00]: All OUTPUT Port, [01...08]: OUTPUT Port
18
PRESET STATUS
Print Preset Config Status
19
PRESET pp SET
aa,bb,cc,dd,ee,ff,gg,hh :
Set Preset:pp Config
20
PRESET pp SAVE
Save Current Output Connection
To Preset:pp Config
21
PRESET pp APPLY
Apply Preset:pp Config To Output Connection
pp=[01..08]: Select Preset Index
aa=[01..08]: Output 01 From aa, [00]: Not Set
bb: Output 02 ... hh: Output 08
22
EDID xx CP yy
Set Input:xx EDID Copy From Output:yy
23
EDID xx DF zz
Set Input:xx EDID To Default EDID:zz
xx=[00]: All INPUT Port, [01...08]: INPUT Port
yy=[01...08]: OUTPUT Port
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH DTS/DOLBY/HD
zz=09: HDMI 4K@30Hz 4:4:4, Audio 2CH PCM
zz=10: HDMI 4K@30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
zz=11: HDMI 4K@30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
zz=15: User EDID 1
zz=16: User EDID 2
zz=17: GUI Download EDID
zz=18: HDMI 4K@60Hz 4:2:0, Audio 2CH PCM
