Brightlink 16x16 - Page 13

13
zz=19: HDMI 4K@60Hz 4:2:0, Audio 5.1CH DTS/DOLBY
zz=20: HDMI 4K@60Hz 4:2:0, Audio 7.1CH DTS/DOLBY/HD
zz=21: HDMI 4K@60Hz 4:4:4, Audio 2CH PCM
zz=22: HDMI 4K@60Hz 4:4:4, Audio 5.1CH DTS/DOLBY
zz=23: HDMI 4K@60Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
24
MXIR xx FR yy
Remote RX:xx IR Output From Local IR in:yy
xx=[00]: All Remote Rx IR Output, [01...08]: Remote Rx IR
Output
yy=[01...08] Local IR In
25
MXIR GI (+-)xx
Global All Ir In Signal Goes To Which IR Output:xx
xx=[09...16]: Local IR Output
xx=[17...24]: Remote HDBT Receiver IR Output
+: Add xx To Current Setting
-: Remove xx From Current Setting
26
MXIR GO (+-)xx
Global All Ir Out Signal From Which IR Input:xx
xx=[09...16]: Local IR Input
xx=[17...24]: Remote HDBT Receiver IR Input
xx=[25]: Global All Ir In
+: Add xx To Current Setting
-: Remove xx From Current Setting
27
MXRS xx TO yy
Local RS-232:xx Route To Remote HDBT:yy
xx=[09]: Global RS-232
yy=[00]: Not Connect To Any RS-232
yy=[09...16]:Remote HDBT Receiveryy=[09...16]: Remote
HDBT Receiver
28
MXSTA
Print Matrix IR And RS-232 Connect State
29
AUD RX xx ORG
Input Port:xx Use Original Received HDMI/DVI Signal
30
AUD RX xx ANA
Input Port:xx Embed Analog L/R To HDMI/DVI Signal
31
AUD RX xx AUTO
Input Port:xx Embed Analog L/R When DVI Signal
xx==[00]: All Input Port, [01...08]: Input Port
32
MUTE ON/OFF TX yy
Set Output Audio:yy Mute On or Off
yy=[00]: All Output Audio, [01...08]: Output Audio
33
AUD STA
Print Input/Output Port Audio Setting State
34
NET DHCP ON/OFF
Set Auto IP(DHCP) ON Or OFF
35
NET IP xxx.xxx.xxx.xxx
Set IP Address
36
NET GW xxx.xxx.xxx.xxx
Set Gateway Address
