Brinkmann 4655 - GRILL ASSEMBLY STEPS: INTERNAL COMPONENTS; STEP 19-21: INSTALLING HEAT PLATES, GRILLS, AND WARMING RACK; STEP 22: IGNITER BATTERY INSTALLATION AND CHECK

Grease Tray
Grease Cup
Step 16
Place side burner grate over side
burner.
Step 17
Insert grease tray into opening on
backside of grill. Make sure to slide
tray onto tracks as illustrated.
Step 18
Slide grease cup into grease cup
bracket located under grill bottom
on backside of grill.
29
Side burner grate
