Step 17
Place the bezel over the valve stem
and position over holes in side
burner base and side burner valve
assembly. Attach with two bolts with
spring washers which come with
valve. Then install the side burner
control knob onto valve stem.
Step 18
Place side burner grate over
side burner.
Step 19
Attach side burner igniter lead to
the electrode as illustrated.
Side Burner Grate
Side Burner Igniter
Lead
Electrode
