ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR SMOKER.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
(PROOF OF PURCHASE WILL BE REQUIRED.)
Inspect contents of the box to ensure all parts are included and undamaged.
1
10
5
2
9
7
PARTS LIST:
1 Horizontal & Vertical Cooking
chambers with attached Firebox
1 Air vent butterfly damper
3 Cooking grill (15
1
⁄
4
" x 12
1
⁄
4
")
2 Cooking grill (15
1
⁄
4
" x 9
1
⁄
4
")
3 Cooking grill (15 dia.)
1 Charcoal grate (18" x 9")
2 Front shelves
1 Firebox door latch
1 Firebox rake
2 Temperature gauges
1 End handle
1
2
3
4
5
6
7
8
9
10
11
3
4
6
8
11
