5
Indicator Panel Description
1. Cold water indicator light - When illuminated, indicates that the dispenser is
cooling water.
2. Hot water indicator light - When illuminated, indicates that the dispenser is heating
water.
3. Bottle indicator light – When ashing, indicates that your water bottle is empty and
needs to be replaced with a new water bottle.
Product Dimensions
Height Width Depth
105.1 cm (41.4 in.) 31.1 cm (12.2 in.) 39.6 cm (15.6 in.)
Operational Specifications
CAUTION: This unit dispenses water at temperatures that can cause severe burns. Avoid direct contact with hot
water. Keep children and pets away from unit while dispensing. Never allow children to dispense hot
water without proper and direct supervision. Unplug unit to prevent unsupervised use by children.
Temperature Tank Capacity Flow Rate
Dispensing Cold
Water
37°-50°F / 3°-10°C 3.6 L
35 mL per second /
1.5L/min
Dispensing Hot
Water
176°–198°F / 80°–92°C 1 L
35 mL per second /
1.5 L/min
Installation
1. Determine Installation Location
A. Place the dispenser upright.
B. Locate the dispenser on a hard and level surface in a cool shaded
location near a grounded wall outlet.
NOTICE: Do NOT plug in the power cord until the entire installation
section is completed.
C. Position the back of the dispenser no closer than 20 cm (8 in.) from a
wall and permit free airow between the wall and water dispenser.
2. Install the Drip Tray and Grid
A. Unwrap the drip tray (8) from the packaging material and slide it onto
the dispenser until it is secure in place.
1 2 3
8
