Brita VIVREAU EXTRA Series - Technical Data

EN | 7170 | EN
TECHNICAL DATA
Tap C-Shape: C-Tap (26 cm) C-Tap (33 cm)
Height 339 mm 409 mm
Depth 269 mm 269 mm
Diameter 36 mm 36 mm
Dispensing height 260 mm 330 mm
Weight 1.9 kg 2.5 kg
Tap I-Shape: I-Tap (26 cm) I-Tap (33 cm)
Height 385 mm 453 mm
Depth 216 mm 216 mm
Diameter 70 mm 70 mm
Dispensing height 260 mm 330 mm
Weight 1.8 kg 2.5 kg
Technical conditions VIVREAU Extra 50 VIVREAU Extra 85
Voltage 220-240 V 220-240 V
Frequency 50 Hz 50 Hz
Max. system inlet water pressure 0.6 MPa / 6 bar 0.6 MPa / 6 bar
Inlet water pressure, min. 0.25 MPa / 2.5 bar (at
2 l/min waterow)
0.25 MPa / 2.5 bar
(at 2 l/min waterow)
Max. relative humidity 60% 60%
Ambient temperature 5 – 25 °C 5 – 25 °C
Unchilled temperature range 16 – 32 °C 16 – 32 °C
Height above sea level < 2000 m < 2000 m
Ideal system operating
inlet water pressure
0.4 MPa / 4 bar 0.4 MPa / 4 bar
Protection Class
/ I / I
Cooler-carbonator VIVREAU Extra 50 VIVREAU Extra 85
Width 272 mm 272 mm
Height 490 mm 490 mm
Depth 473 mm 473 mm
Weight 33 kg 38.5 kg
Current, max. 2.0 A 2.4 A
Power consumption, max. 440 W 540 W
Cooling Performance 50 l/h 85 l/h
CO
2
operation pressure 0.45 MPa / 4.5 bar 0.45 MPa / 4.5 bar
Flow rate 2 l/min 2 l/min
Refrigerant: R290 54 g 68 g
Noise emission < 57 dB (A) < 60 dB (A)
Boiler Medium Large
Width 230 mm 230 mm
Depth 234 mm 234 mm
Height 415 mm 670 mm
Weight 7.8 kg 11.3 kg
Flow rate 1,0 l/min 1,3 l/min
Current, max. 9 A 9 A
Power consumption, max. 2,10 0 W 2,100 W
Heating performance 20 l/h 30 l/h
