FRONTIER/PINNACLE CLICKTIGHT User Guide
3� Turn and push the buckle
retainer through the slot in
the child seat shell�
4� Pull the EZ-Buckle
belly pad through the
corresponding slot in the
seat cover� Place the seat
cover back in its original
position and attach the
retaining clips�
5� Hook the harness straps
to the CLICKTIGHT hip
anchors�
NOTE: Ensure that the
harness is attached to the
top of the hip anchor.
6� Insert the harness straps
through the slots in the
cover and shell, and over
the harness adjuster plate
to the back of the child
seat�
7� Nest the harness straps
by inserting the right strap
loop into the left strap
loop�
8� Remove the harness yoke
from storage underneath
the seat shell and slide
the nested harness straps
completely onto the
harness yoke�
9� Close the CLICKTIGHT�
A click confirms the
CLICKTIGHT is secure�
10� Buckle the harness and
pull the adjuster strap to
tighten the harness�
NOTE: Pull the harness
adjuster away from the
child seat (parallel to the
ground) to tighten.
IMPORTANT: Check all attachments before using the
child seat�
Uninstalling the Seat
1� Unbuckle the vehicle seat
belt�
NOTE: For car seats
installed with lower
connectors, see page 27.
2� Open the CLICKTIGHT�
