Fitting the Seat Forward Facing –Alternative Routing ‘B’
Thread the diagonal section of the seat-belt
through the red seat-belt lock. Make sure you
pull the seat-belt in the direction of the arrow.
10
Undo the buckle of the car seat-belt.
And re-fasten it so that it lies in the area
between the tubular frame and the plastic
moulding as shown on the routing label 'B'.
9
IMPORTANT – The First Class Si has two red seat-belt locks. ONLY USE the one
FURTHEST away from the seat-belt buckle.
Pull here to tighten the diagonal section of the
seat-belt. It is essential to make sure that the
belt is pulled through the red seat-belt lock at
the correct angle, or else the belt will bunch
and come out.
11
Option
Option
B
Thread the belt around the diagonal seat-belt
guide on the side of the seat.
12
