Britax PRINCE - MY Crucial Parts of Your Child Car Seat; Product View and Parts

Crucial parts of your child car seat
Types of seat-belt
You need to know these before installing the PRINCE in your car.
This is a lap
and diagonal
seat belt
This is a lap-belt
Diagonal
section
Lap section
1. Chest pads
2. Harness
3. Buckle
4. Adjuster button (behind the cover)
5. Adjuster strap
6. Recline bar
7. Release handle
8. Red seat-belt lock
9. Side slot
10. Cover
11. Side slot
12. Connection Piece
(behind seat-belt guard)
13. Base
14. Shoulder slots
15. Shoulder straps
16. Chest pad tabs
(behind shoulder straps)
17. Lap belt guide
18. Seat-belt guard
19. Adjuster strap
14
15
16
17
18
19
1
2
3
4
5
6
7
8
9
10
11
12
13
page 2
The PRINCE can be used with either a lap and diagonal seat-belt or a lap-belt (approved to UN/ECE
Regulation No.16 or equivalent standards).
