Stage 2 - Installing the PRINCE in the car
page 5
Have you adjusted the harness to the correct position for your child?
If not, see Stage 1 on page 3.
Installing with a lap and diagonal seat-belt
IMPORTANT - Do not use any load bearing contact points other than those described in the instructions and
marked in the child restraint.
6
Pass the seat-belt through both side slots.
1
2
Fasten the seat-belt.
3
5
4
Lap belt
guide
Press the red lock open.
.
Place the PRINCE forward facing on the car seat and
pull the harness tight.
Pull the diagonal section through the red lock. Make
sure that the seat belt is not twisted.
Before going any further make sure that the lap section of the
seat-belt passes below both lap belt guides.
To Next Page
