Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
30
INSTALLER COMMISSIONING
INSTRUCTIONS; (cont.)
Wiring the Cooler to the Networker; (cont.)
If more than one Cooler is connected on the system to one Networker, then all the
coolers will be wired in parallel to the Networker as shown. Ensure each Cooler is
then configured correctly to the Networker, using the instructions on page 24.
Networker
Cooler No. 1
Cooler No. 2
Cooler No. 3
