Brivis contour Service Manual

Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
88
Trident Water Management System (cont.)
Trident Test Procedure & Service Checks (cont.)
RED
WHITE
BLACK
Guard Water
Sensor
Loom Cntrl-
Water Sensor
MOTOR
SPEED
SENSOR LOOM
WATER LEVEL
CONTROL LOOM
J 5
J 6
J 1
J 2
NETWORKER
LOOM
ALTERNATIVE
NETWORKER
CONNECTION
POINT
High Water Level
Common Sensor
Low Water level
OFF
10 A
V
COM
FUSED
1000V - - -
750V
V
VOLTS
14
14 Volts - Dry
When water makes closed circuit
must be less than 9 volts - Wet
Common Sensor and Low Water Level
Heatshrink Sensor
Strip (100mm)
Common
Pin
Low Water
Sensor Pin
Plastic Guide
