INSTALLATION, START-UP & MAINTENANCE
INSTRUCTIONS
1.0 INTRODUCTION
Read all instructions before proceeding with the installation and start up.
• This equipment must be installed in accordance with all relevant regulatory authority and industry requirements.
• Only qualified, licensed technicians shall perform works on these units; failure to do so will result in warranty being
void.
• Definitions:
“Shall” indicates a mandatory requirement of this manual
“Should” indicates a recommended requirement of this manual
• Deviation from these instructions, may at the discretion of Brivis, void the warranty. As a result, the homeowner
and or installer may be charged a fee for non-product warranty related call outs. Also note that failure to comply
with these instructions may preclude Brivis from being able to service the appliance.
THE USER SHOULD RETAIN THIS MANUAL FOR FUTURE REFERENCE.
1.1 Brivis ICE R410a Inverter Range
The Brivis Inverter ICE series is a refrigerated cooling split only type air conditioner designed for connection to compatible
Brivis Ducted Gas Heaters. Brivis Inverter ICE utilises the heating system’s ductwork and air circulation fan to distribute
cool, filtered refrigerated air.
ICE
Outdoor Model
ICE
Indoor Model
Nominal Cooling
Capacity - kW
Rated Cooling
Capacity - kW
(Range)
Recommended Brivis
Gas Ducted Heater Model
DONSC10Z7 DINXU10Z7 10 9.3 (4.8 -10.1)
DONSC13Z7 DINXU13Z7 13 12.4 (6.3 -13.6 )
DONSC15Z7 DINXU15Z7 15 14.7 (7.5 -16.0)
Refer to latest Brivis Gas Ducted Heater
Specifications for Maximum
Recommended Add-On Cooling Capacity
Table 1 – Brivis ICE Models and Heater Compatibility
• Some heaters may require a transition to modify its starting collar (pop) size to suit the inlet pop size of the ICE
indoor coil. DO NOT REDUCE POP SIZES ON INDOOR COIL or HEATER.
• Ensure minimum specified air quantity requirements passes through the ICE cooling coil at all times
• Ductwork and fittings must be sized to handle the total cooling airflow through the system on either whole home or
zoned basis.
1.2 Safety / Warnings
The unit is designed to provide safe and reliable service when operating within design specifications. To avoid injury to
personnel and damage to equipment or property when operating the equipment, the following safe practices should be
observed as a minimum.
• Check the unit weight to be sure the lifting equipment is adequate
• Disconnect power to the unit before working on it
• Do not remove access panels or doors until fans have completely stopped
• Do not enter a fan cabinet while the fan is running
• Protect materials when welding or flame cutting. Use suitable cloth to contain sparks. Have a fire extinguisher at
hand and ready for immediate use
• Do not place articles on or against this appliance
• Do not use or store flammable materials near this appliance
• Do not spray aerosols in the vicinity of this appliance while it is in operation
• Do not modify this appliance
Note: The communication cable installed between the indoor coil and outdoor unit shall be:
1. Field supplied
2. 3-core shielded cable
3. Earthed at the CDU end, refer to Fig.14
